Specifications | ||||||||||||
MODEL NO. | BEARING | RATED | SIZE | SIZE | SIZE | RATED | RATED | SPEED | AIR | STATIC | NOISE | |
VOLTAGE | MM | MM | MM | CURRENT | POWER | FLOW | PRESSURE | |||||
VDC | A | B | C | A | W | R.P.M | CFM | M 3/MIN | mmAq | db(A) | ||
JCD430924HBA | Ball | 24 | 98 | 108 | 134 | 0.18 | 4.3 | 2800 | 24 | 0.7 | 1.8 | 36 |
JCD431524HBA | Ball | 24 | 160 | 170 | 196 | 0.25 | 6.0 | 2500 | 42 | 1.2 | 1.2 | 37 |
JCD431924HBA | Ball | 24 | 198 | 208 | 239 | 0.22 | 5.3 | 2400 | 53 | 1.5 | 1.0 | 39 |
JCD432424HBA | Ball | 24 | 250 | 260 | 306 | 0.30 | 7.2 | 2700 | 78 | 2.2 | 1.1 | 43 |
JCD432924HBA | Ball | 24 | 300 | 310 | 356 | 0.30 | 7.2 | 2600 | 85 | 2.4 | 1.0 | 43 |
JCD433524HBA | Ball | 24 | 360 | 370 | 416 | 0.35 | 8.4 | 2500 | 95 | 2.7 | 1.0 | 45 |
